POWER CABLE SOLUTIONS FOR SWITZERLAND
Various GKN cable types with copper and aluminum conductors and for TN-C and TN-S systems for the Swiss low-voltage networks. XKDT types for use in the Swiss medium-voltage grids, up to supply lines and installation cables, such as FE0 NN-CLN.
Low voltage power cables
BayEnergy® GKN
acc. to HD 603 S1 part 7E
BayEnergy® GKN 1-conductor and 3-conductor | 5-conductor TN-S
BayEnergy® GKN Flex
based on HD 603 S1 part 7E
BayEnergy® GKN-Flex 1-conductor and 3-conductor | 5-conductor TN-S
BayEnergy® GKN Alrm
acc. to HD 603 S1 part 7E
BayEnergy® GKN Alrm 1-conductor to 3-conductor | 5-conductor TN-S
BayEnergy® GKN Alse
acc. to HD 603 S1 part 7E
BayEnergy® GKN Alse 3-conductor
BayEnergy® GKN Alsm
in accordance with HD 603 S1 part 7E
BayEnergy® GKN Alsm 3-conductor | 5-conductor TN-S | 5-conductor combi EMV TN-S
BayEnergy® GN-CLN
acc. to HD 603 S1 part 8B
BayEnergy® GN-CLN 3-conductor, 4-conductor und 5-conductor
BayEnergy® GN-CLN-Al
based on HD 603 S1 part 8B
BayEnergy® GN-CLN-Al 4-conductor/5-conductor
BayEnergy® XN-CLN Al
acc. to HD 603 S1 part 6C
BayEnergy® XN-CLN Al 4-conductor
Medium voltage power cables
BayEnergy® XKDT 12/20 kV
XLPE insulation, Cu shield, PE sheath, based on DIN VDE 0276-620
BayEnergy® XKDT 1-copper coductor | 1-aluminium conductor
BayEnergy® XKDT-Y 12/20 kV
XLPE insulation, Cu shield, PE sheath, based on DIN VDE 0276-620
BayEnergy® XKDT-Y 3-copper conductor | 3-aluminium conductor
BayEnergy® XKDT-YT 12/20 kV
XLPE insulation, Cu shield, PE sheath, based on DIN VDE 0276-620
BayEnergy® XKDT-YT 3-conductor, copper, common sheath | 3-conductor, aluminium, common sheath
Supply & installation cables
Power connection lines acc. to Bayka standard
based on HD 603 S1 part 7E and HD 604 part 5G
BayMotion® B2ca FE05B 0,6/1 kV (CH-N1ZZ1-K) single-core
based on IEC 60502-1 and HD 604
BayMotion® nonfire Power Soil
1-core 0,6/1 kV | 1-core 1,8/3 kV | 2-7-cores 0,6/1 kV
acc. to Bayka standard
BayMotion® Eca Flex Power +
1-core 0,6/1kV | 3-5-core 0,6/1kV | 1-core 1,8/3kV
BayMotion® Power PUR FR 1x… 0,6/1 kV
BayMotion® Eca Flex Power + stranded
Installation cable
based on HD 603 S1 part 7E and HD 604 part 5G
BayMotion® B2ca FE05B 0,6/1 kV (CH-N1ZZ1-K) single-core
based on Electrosuisse TPV-007 FE0
BayEnergy® FE0 NN-CLN 2- to multicore
based on HD 604 part 5G
BayEnergy® Eca FE0-CLCuE-R 1-core
Low voltage power cable
acc. to HD 603 S1 part 8B
BayEnergy® GN-CLN 3-core/4-core/5-core
acc. to respectively based on HD 603 S1 part 8B
BayEnergy® GN-CLN Al 4-core/5-core
Control cable
highly flame retardant, shielded, UV and weather resistant, ozone resistant, directly buriable, oil resistant, flexible, acc. to IEC 60502-1 and Bayka standard
BayMotion® nonfire soilblack EMC
halogen free, flame retardant, shielded, UV and weather resistant, ozone resistant, acc. to IEC 60502-1, acc. to NOK TE5542 Rev.04
BayMotion® EMV Control Soil FRNC
UV-resistant, acc. to DIN VDE and Bayka standard
BayMotion® YSLYK-JZ UV-Flex | YSLCYK-JZ EMC-UV-Flex
Low capacitance motor connection cables
Low capacitance motor connection cables, highly flame retardant, shielded, UV and weather resistant, ozone resistant, directly buriable, oil resistant, flexible, acc. to IEC 60502-1 and Bayka standard
BayMotion® nonfire soilblack EMC
BayMotion® nonfire soilblack VFD EMC 3+3
Low capacitance motor connection cables, highly flexible, oil resistant, PUR, acc. to Bayka-standard
BayMotion® BayMotion® EMC PUR | BayMotion® VFD EMC PUR 3+3
Low capacitance motor connection cables, VPE-isolated, acc. to Bayka-standard
BayMotion® 2XSLCYK-J EMC-UV-Flex (XLPE)
Low capacitance motor connection cables, halogen free, flame retardant, acc. to Bayka-standard
BayMotion® 2YSLCHK-J EMC-UV-Flex 3+3 FRNC | 2XSLCHK-J EMC-UV-Flex 3+3 (XLPE) FRNC
DC-optimised cables
BayMotion® CPR feedIN DC, Highly flexible, halogen-free, flame-retardant, UV and weather-resistant, directly buriable
BayMotion® CPR feedIN DC (with concentric conductor)
BayMotion® CPR feedIN DC EMC (with EMC screen)
BayMotion® CPR feedIN DC EMC+ (with EMC screen and concentric conductor)
BayMotion® nonfire feedIN DC, Highly flame-retardant, halogen-free, flexible, UV and weather-resistant, directly buriable and oil resistant
BayMotion® nonfire feedIN DC (with concentric conductor)
BayMotion® nonfire feedIN DC EMC (with EMC screen)
BayMotion® nonfire feedIN DC EMC+ (with EMC screen and concentric conductor)
Overhead lines (aerial cables)
Overhead lines / aerial cables (XLPE-isolated)
BayEnergy® XLPE-isolated overhead lines / aerial cables, acc. to DIN VDE 0276-626
NFA2X 1-6-core 1-6-core process B
BayEnergy® roof stand-connection line for XLPE-isolated overhead lines / aerial cables, acc. to DIN VDE 0250-213
NYDY 4-core
Fireproof Cables acc. to the CPR
